Size	Thread Size 'C'		Minimum Length of Thread 'D'	Cable Range
Size	MM	INCH	Minimum Length of Thread 'D'	MAX 'A'	MAX 'B'
BW 20S	20	3/4	10	13.00	15.50
BW 20L	20	3/4	10	14.00	18.50
BW 25L	25	1	10	20.50	26.00
BW 32L	32	1.1/4	10	27.00	33.90
BW 40L	40	1.1/2	15	33.00	41.50
BW 50S	50	2	15	38.50	47.00
BW 50L	50	2	15	44.00	52.00
BW 63S	63	2.1/2	15	51.00	59.20
BW 63L	63	2.1/2	15	56.50	65.50
BW 75S	75	3	15	63.00	74.00
BW 75L	75	3	15	68.50	79.50
BW 90L	90	3.1/2	20	80.50	91.00

Size	Thread Length	'A'	'B'	A/F	A/C
20S	M20 10.00	13.00	18.00	23.50	26.00
20L	M20 10.00	14.00	21.00	25.00	28.00
25S	M25 10.00	18.00	24.00	31.00	35.50
25L	M25 10.00	20.50	27.00	33.00	37.00
32S	M32 10.00	27.00	33.50	40.50	45.50
32L	M32 10.00	27.00	33.50	40.50	45.50
40S	M40 13.00	31.50	39.50	45.50	50.50
40L	M40 13.00	33.00	41.50	49.00	55.00
50S	M50 13.00	39.50	48.50	56.50	63.50
50L	M50 13.00	44.50	54.50	62.50	70.50
63S	M63 14.00	50.20	59.20	68.80	77.00
63L	M63 13.50	56.50	65.50	76.00	86.00
75S	M75 15.00	63.50	72.00	84.00	94.50
75L	M75 15.00	69.50	78.50	90.00	101.00
90S	M90 20.00	76.00	85.00	100.00	111.20
90L	M90 18.00	78.40	90.50	103.00	115.00

CW Type Gland Specifications
Gland Size	Entry Threads		Cable Acceptance Details		Hexagonal details		PVC
	Dia	Length	Dia	Dia	A/F	A/C	Shroud
	N'	D'	A'	B'	F'	C'	Size
CW 20S	20	15	11.80	17.80	24.00	27.00	20S
CW 20L	20	15	15.00	20.80	27.70	31.00	20
CW 25S	25	15	17.60	24.00	31.50	35.00	25
CW 25L	25	15	20.00	27.40	35.00	39.00	25
CW 32S	32	15	25.70	32.20	43.00	47.50	32
CW 32L	32	15	26.00	34.20	43.00	47.50	32
CW 40S	40	20	30.40	38.00	51.50	57.00	40
CW 40L	40	20	33.20	40.50	51.50	57.00	40
CW 50S	50	20	39.70	47.00	58.50	65.00	50
CW 50L	50	20	43.50	54.00	66.00	73.00	50
CW 63S	63	20	51.50	61.00	72.00	80.00	63
CW 63L	63	20	55.00	66.00	80.00	89.00	63
CW 75S	75	20	62.50	74.50	86.50	97.00	75
CW 75L	75	20	67.80	77.50	94.00	105.00	75
CW 90	90	20	84.00	96.00	106.00	118.00	90

Size	Thread	Length	'A'	'B'	A/F	A/C
20S	M20	15.00	12.00	16.00	22.20	24.20
20L	M20	15.00	144.00	20.50	27.00	29.50
20/16	M20	15.00	9.00	14.00	22.20	24.20
25S	M25	15.00	18.50	24.50	33.50	37.50
25L	M25	15.00	20.50	27.50	36.00	40.00
32S	M32	10.40	24.30	34.00	43.00	48.50
32L	M32	15.00	26.27	34.20	43.50	48.50
40S	M40	15.00	29.50	41.50	52.00	58.00
40L	M40	15.00	33.00	41.50	52.00	58.00
50S	M50	15.00	38.50	47.00	59.00	65.50
50L	M50	15.00	44.30	53.20	64.20	71.50
63S	M63	20.00	50.20	62.50	73.50	81.50
63L	M63	20.00	56.20	65.50	79.50	89.00
75S	M75	20.00	62.00	74.00	87.00	97.00
75L	M75	20.00	68.00	78.20	97.00	108.00
90L	M90	18.50	80.00	91.00	103.50	114.50

Size	Thread Size 'C' Metric	Min Length 'D'	'A' Max	'B' Max
G-204	20	10	12.50	17.00
G-206	20	10	14.00	21.00
G-254	25	10	18.00	24.00
G-256	25	10	20.50	27.00
G-324	32	10	23.50	29.50
G-326	32	15	27.50	34.00
G-405	40	15	33.50	41.50
G-503	50	15	39.50	48.50
G-505	50	15	44.50	54.50
G-636	63	15	56.00	65.60
G-753	75	15	63.50	72.00
G-755	75	15	69.50	78.50

Size	A	B	C	D	E	F	G
PG-7	14.00	15.50	20.50	PG-7	10.00	5.00	150
PG-9	18.00	20.00	23.50	PG-9	12.50	6.00	150
PG-11	20.00	22.00	26.50	PG-11	15.00	6.50	150
PG-13	23.00	25.00	27.00	PG-13	16.75	7.10	150
PG-16	25.00	27.80	28.00	PG-16	18.50	6.50	150
PG-21	31.00	34.00	31.00	PG-21	24.10	7.10	150
PG-29	41.50	45.20	34.00	PG-29	32.10	8.50	150
PG-36	51.00	56.00	40.00	PG-36	43.00	10.00	150
PG-42	58.50	63.75	43.00	PG-42	47.50	10.00	150
PG-48	64.00	70.50	47.00	PG-48	52.25	10.00	150

Size	Thread Size 'C'		Thread Length 'D'	Cable Range Dia.		Across Flat	Across Corners	CAT NO.
Size	Metric	NPT	Thread Length 'D'	MIN 'A'	MIN 'B'	Across Flat	Across Corners	CAT NO.
16	16	-	15	3.10	8.60	21.00	23.00	CCXT-16
20S	20	½"	15	6.10	11.60	24.00	26.50	CCXT-20S
20	20	½"	15	6.50	13.90	27.00	30.00	CCXT-20
25	25	¾"	15	11.10	19.90	36.00	39.75	CCXT-25
32	32	1"	15	17.00	26.15	41.00	46.00	CCXT-32
40	40	1¼"	15	22.00	32.10	49.25	55.00	CCXT-40
50S	50	1½"	15	29.80	38.10	54.75	61.30	CCXT-50S
50	50	2"	15	36.90	43.30	60.00	66.50	CCXT-50
63S	63	2"	15	42.20	49.90	70.25	77.50	CCXT-63S
63	63	2½"	15	48.30	54.90	74.75	83.00	CCXT-63
75S	75	2½"	15	54.20	62.00	80.00	89.00	CCXT-75S
75	75	3"	15	59.80	66.90	84.00	94.00	CCXT-75
90	90	3"	18	66.60	79.30	107.00	118.00	CCXT-90

Metric Thread Entry Size	Dimensions			Braid Thickness Maximum	Equivalent Imperial Thread Size	Minimum Entry Thread Length 'D'	Assembled Length excl. Thread Entry 'E'	Brass Lock Nuts A/F	Hexagon Size 'F' On Gland Body A/F
Metric Thread Entry Size	Bore 'A'	Cable 'B'		Braid Thickness Maximum	Equivalent Imperial Thread Size	Minimum Entry Thread Length 'D'	Assembled Length excl. Thread Entry 'E'	Brass Lock Nuts A/F	Hexagon Size 'F' On Gland Body A/F
MM	MM	MIN	MAX	MM	Inches	MM	MM Appx.(Maximum)	MM	MM
MM	MM	MM	MM	MM	Inches	MM	MM Appx.(Maximum)	MM	MM
20/16	8.7	8.0	13.5	0.85	3/4	10.0	41	22	23
20S	11.7	11.2	16.0	0.85	3/4	10.0	44	24	23
20	14.0	13.2	21.0	0.85	3/4	10.0	46	24	26
25	20.0	15.5	24.0	0.9	1	10.0	51	30	33
32	26.3	26.4	34.0	1.25	1¼	10.0	51.5	36	41
40	32.2	31.5	40.5	1.4	1½	15.0	55	46	50
50S	38.2	36.4	46.8	1.4	2	15.0	54.5	55	61
50	44.1	42.9	52.8	1.4	2	15.0	70	55	63
63S	50.0	46.8	60.5	1.5	2½	15.0	80	70	84
63	56.0	58.4	65.5	1.5	2½	15.0	80	70	85
75S	62.0	60.0	71.8	1.5	3	15.0	96	80	100
75	68.0	66.7	78.1	1.5	3	15.0	96	80	100

Size	Thread Size 'C'	Minimum Length of Thread 'D'	Cable Range		MAX 'A'	MAX 'B'
Size	Thread Size 'C'	Minimum Length of Thread 'D'	MM	INCH	MAX 'A'	MAX 'B'
A2	20S	20	3/4	15	10.80	8.80
A2	20L	20	3/4	15	14.70	11.40
A2	25S	25	1	15	16.00	13.00
A2	25L	25	1	15	20.30	17.30
A2	32S	32	1.1/4	15	23.00	20.00
A2	32L	32	1.1/4	15	26.20	24.20
A2	40S	40	1.1/2	20	29.00	26.00
A2	40L	40	1.1/2	20	34.00	29.50
A2	50S	50	2	20	41.00	33.00
A2	50L	50	2	20	45.00	38.00
A2	63S	63	2.1/2	20	51.50	44.00
A2	63L	63	2.1/82	20	56.50	50.00
A2	75S	75	3	20	63.20	56.00
A2	75L	75	3	20	68.50	62.00

Product Code	Pipe Thread	Gland ID in mm A	Rubber ID	Locknut OD in mm C	Gland OD in mm D	Total Length L
ACG 10	PF 3/8	10	8	28	22	38
ACG 15	PF 1/2	15	10	31.5	28	42
ACG 20	PF 3/4	20	13	37	33.5	46
ACG 25	PF 1	25	15	45	42	52
ACG 30	PF 1¼	30	24	46	49.5	57
ACG 35	PF 1½	40	30	63	55	65
ACG 40	PF 1½	40	34	63	55	65
ACG 45	PF 2	45	38	77	69	73
ACG 50	PF 2	50	44	77	69	73
ACG 55	PF 1/2	55	48	96	85	83
ACG 60	PF 1/2	60	54	96	85	83
ACG 65	PF 3	65	60	112	100	95
ACG 70	PF 3	70	64	112	100	95
